● Uses high-precision stainless steel sensors with laser welding sealing.
● Height adjustable.
● Overall accuracy: 0.05% F.S.
● Equipped with tilt-over protection and overload protection.
● Cable length: 6m (customizable).
● Suitable for high-precision batching, reaction vessels, force measurement platforms, etc.
● Provides special high-temperature version (up to 200℃).
● Available in stainless steel and carbon steel structures.
● This is a patented product, and infringement will be pursued.
● Application areas: automobile assembly, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
| Rated range | 5t | Insulation resistance | ≥5000MΩ/100VDC |
Output sensitivity | 2.0±0.1%mV/V | Excitation voltage | 5-12V |
Zero output | ±3%mV/V | Maximum excitation voltage | 15V |
| Nonlinearity | 0.05%F.S. | Temperature compensation range | -10~40℃ |
| Hysteresis error | 0.05%F.S. | Operating temperature range | -40-80℃ |
| Repeatability | 0.05%F.S. | Safe overload | 150%F.S. |
| Creep (30 minutes) | 0.05%F.S. | Ultimate overload | 200%F.S |
| Temperature coefficient of sensitivity drift | 0.05%F.S./10℃ | Protection | IP66 |
| Temperature coefficient of zero drift | 0.05%F.S./10℃ | Cable size | φ6-6m |
Input resistance | 780±20Ω | ||
Output resistance | 700±10Ω | ||
Direction of force | Wiring method |
 |  |
