● High precision: Certification accuracy of 10000e, maximum display scale of 60000.
● Anti-vibration technology: Faster and more stable display for tank weighing applications.
● Easy operation: Large screen with Chinese display and guided menu settings.
● Rich interface options: RS232, RS485, Ethernet, USB, and more.
● Strong anti-interference capability: Fully isolated design for communication interfaces, surge protection design.
● Application areas: Automotive press fitting, automation assembly, 3C product testing, assembly of new energy products, medical testing, robotics, mold assembly, and other industrial testing, measurement, and control systems.
Features | Stainless Steel Casing | Protection Rating | IP67 |
Display | 5InchesLCD，240X128Dot, White Background with Black Text | Exc Voltage | 5-12V |
Keypad | Full-featured Keyboard: Navigation Keys, Function Keys, Soft Keys, Numeric Keys | Accuracy | IIILevel n≤10000 |
Graduation | 1,000~60,000 | Sensor Capability | Max Number of Connections16个350Ohm Sensor |
Scale Platform Connection | Analog SensorHBM / Keli E / ZEMIC / AWTDigital Sensor | A/DSpeed | 120T/S |
Sensor Exc Voltage | DC 10V / 500mA | Digital Sensor Interface | RS485 / RS422Interface, Surge Protection, and Lightning Protection |
AC Power Supply | 100 ~ 240VAC / 50 ~ 60Hz Wide Voltage Input | Operating Temperature | -10 ~ 40℃ |
Communication Interface | RS232、RS485、Ethernet(Optional)、USB(Optional)、 4～20mA / ±10V(Optional)、4In6Out(Optional) | Unit | Kg、t |
System Application Topology Diagram |
 |
