● ly used in platform scales, vehicle scales, over/under sorting scales, counting scales, and livestock scales.
● Output supports RS232, RS485, WiFi, Ethernet TCP/IP, and Bluetooth.
● 6-digit LED display with a height of 33.4mm in red or green color.
● Basic weighing functions: zero, tare, clear, and print, with additional features such as auto tare, auto clear, and auto print.
● Built-in various applications: upper/lower limits, check weighing, preset points, and peak value capture comparison.
● The controller power supply uses AC 100~264VAC with a current of 0.1A. It can also be powered by a rechargeable Nickel-Hydrogen battery pack of GP7.2VDC 3800mAh (optional).
● Stainless steel waterproof casing with a Protection Rating of IP66, with the option of a plastic casing.
● Application areas: platform scales, vehicle scales, over/under sorting scales, counting scales, and livestock scales.
Display Window | 6-digit red/green LED display | Read | 10000 e |
Measurement Sensitivity | ≥0.5 μV/e | Minimum Sensitivity | 200000 d |
Output Linearity | 0.002% | Overall Accuracy | Better 0.01% |
A/D Conversion Speed | ≤50T/S | Acceptance Sensitivity | 0.1~+20 mV |
Input Load | 4 of 3500 sensors | Interface | RS485/RS232--Modbus |
Fullcale Temperature Drift | ≤10ppm /℃ | Zero Temperature Drift | ≤10μV /℃ |
Exc Voltage | 5VDC | Power Supply | 100~240VAC/50~60HZ |
Overall Power Consumption | ≤10W | Operating Temperature Range | -20~70℃ |
Unit Weight | 1kg | Material | Pl or Stainless Steel Optional |
Protection Rating | IP66 |
